K2k Manual Hospital Bed (SK-C1)
Highlights
Head & foot board
The head and foot boards feature “integrated protective corners”with hollow design, which are combined with barrel-type bumper wheels that have a diameter of 60mm.
This design not only minimizes the overall space occupied by the bed but also provides protection.
Additionally, the head and foot boards are effortless to disassemble and clean.
Castors
5” covered castors.
TPR material, walks 30KM with no wear and tear.
Precision-designed anti-winding shell with no screws.
Pass Dynamic test :withstand a weight of 120kg, walk 30KM, and pass through 500 obstacles without any deformation or damage.
Platform
Stamping forming bed platform features a robot-welded surface that has been polished to perfection, leaving no welding scars.
Bearing 200kg.
Siderail
The siderails are made of aluminium alloy horizontal bar, 6 vertical stainless steel poles and aplastic handle.
Hand Cranks
Two retractable hand cranks tocontrol backrest and kneerest.
The hand cranks remain intact after 100,000 uses.
Drainage Hooks
Injection molded drainage hookson both sides of the bed.
IV Pole
The infusion pole is made of stainless steel and has four plastic hooks that can bear up to 15kg of weight.
Technical Parameters & Optional
Technical parameters
| External size (LxW): | 2160x980 mm±10mm |
| Mattress platform: | 1930x830 mm |
| Safe workingload: | 200 kg |
| Height adjustment: | 505 mm |
| Back-rest adjustment: | 0-80°(±10°) |
| Knee-rest adjustment: | 0-35°(±10°) |
Technical configuration
| Manual Cranks | 2pcs |
| 5" Covered Castors | 4pcs |
| Foldable Side Rail | 1set |
| PP Bed Ends with Safe Lock | 1set |
| IV Pole | 1set |
| IV Pole Prevision | 4pcs |
| Drainage Hook | 2pcs |
Optional
200kg
Safe working load
80°±10°
Back-rest adjustment
35°±10°
Knee-rest adjustment
FAQs – Manual Hospital Bed
Q: What is the safe working load of this manual bed?
A: 200 kg – sturdy construction ensures reliable patient support and safety.Q: How durable are the hand cranks?
A: Tested to 100,000 uses without failure – long-lasting mechanical reliability.Q: What are the bed adjustment ranges?
A: Backrest: 0–80° (±10°); Knee-rest: 0–35° (±10°); Fixed height: 505mm.Q: How durable are the castors?
A: 5" covered TPR castors – 30KM walking test with 120kg load, pass 500 obstacles, no wear or deformation.Q: What is special about the head and foot boards?
A: Integrated protective corners with 60mm bumper wheels – space-saving and protective. Easy to disassemble and clean.Q: What material are the siderails?
A: Aluminum alloy horizontal bar, 6 vertical stainless steel poles, and plastic handle – strong and hygienic.Q: How is the bed platform constructed?
A: Stamping forming with robot-welded surface, polished to perfection – no welding scars, bearing 200kg.Q: What are the external dimensions?
A: 2160×980mm (L×W) with mattress platform 1930×830mm.Q: What standard accessories are included?
A: 2 manual cranks, 4 castors, foldable side rail, PP bed ends with safe lock, IV pole, 4 IV pole prevision, 2 drainage hooks.Q: What optional features are available?
A: Various options available – contact us for specific requirements.Q: Is the IV pole sturdy?
A: Stainless steel with 4 plastic hooks – bears up to 15kg weight.Q: Where are the drainage hooks located?
A: Injection molded hooks on both sides of the bed for convenient access.
